The survey work for the intake tower included GPS, 3D laser scanning, UAV, and multi-beam bathymetry. The team used GPS to establish primary control from which to base the survey, and then extended that control network around the site with a conventional total station.
Ross Road is located between Mountain Highway and Allan Road in North Vancouver. McElhanney is designing replacement bridges for the aging Coleman Creek and Hastings Creek Bridges. This involves raising both the roadway approaches and bridges to achieve the maximum freeboard possible.
McElhanney gathered laser scanned data, converted it into a 3D model, then brought it into Virtual Reality software. This is a relatively simple virtual reality experience where the user can move around the station by walking or teleporting.
The 3D visualization for this project needed to show what No. 2 Road would look like after the widening between Steveston Highway and London Road was finished. Our team took photos from 5 specific locations to so the surroundings in the rendering could be accurate.
3D Photorealistic renders were required to showcase the design of this roundabout. CAD files were provided to model the roundabout as well as the terrain. After adding textures, lights and 3D models the renders were retouched to produce the final 3D imagery. The Contractor used these renderings to communicate the project to residents and stakeholders.
This Virtual Reality experience shows the potential of this technology and its benefits for project proposals, public forums, marketing, stakeholder engagement, and more. Laser scanned data, CAD models, and 3D models were used along with programming to create this fully immersive experience.
McElhanney provided bridge design and engineering services for the Sultanganj bridge project. Our team created 3D photorealistic renderings to illustrate the article. This rendering included a detailed 3D model with textures, scenery, and vehicle traffic.
McElhanney is providing a wide array of services for this project including structural, civil, and hydrological engineering, environmental, visualization, and arborist services. McElhanney developed the images to help illustrate the project concept.
McElhanney created the Banff Upper Hot Springs 3D model using laser scanned data. This Virtual experience brings in weather and vegetation. Users can move around the historical site allowing them to view it in detail. This 3D model will provide our team with important details to support the project.
High River, AB – The Town of High River, Alberta, had an outdated set of bylaws which dated back to 1980. McElhanney was retained to re-write the Town’s Land Use Bylaw based entirely on walkability; the first of its find in Alberta.
