Pattullo Bridge Deck Rehabilitation

TransLink and the Ministry of Transportation and Infrastructure brought on McElhanney as the prime consultant to address deck repairs and create both a traffic management plan and an operations plan. The result was comprehensive plan that allowed the bridge deck rehabilitation to be completed and re-opened ahead of schedule.

Port Mann Highway 1 Roadworks and Detour Designs

During construction, more than 120,000 vehicles drove over the Port Mann Bridge every day, ranging from commuters (travelling 80km/h) to slow-moving construction machinery. The detour designs needed to incorporate HOV lanes, cycling lanes, and dedicated bus and truck ramps, and ensure high-speed and low-speed traffic did not mix.

View Royal Sanitary Master Plan

McElhanney was hired to update View Royal’s sanitary system models to reflect current operating conditions, assess existing system conditions and service life, and prepare a capital plan list to prioritize short- and long-term upgrades.

Veer Kunwar Singh Setu

The Veer Kunwar Singh Setu is a four lane highway bridge over the Ganga (Ganges) River near Patna in Bihar, India. It was procured through a Design-Build contract. McElhanney successfully value engineered an extradosed segmental bridge concept with 16 back-to-back 120m-long spans that reduced construction duration and material consumption for the 1,920m navigation spans portion of the 4km bridge. Approach spans outside the navigation spans utilizes precast segmental erected in span-by-span. The bridge opened in June 2017.

Uplands Combined Sewer Separation

McElhanney developed six options for Upland’s separate sewer and stormwater systems with service to each residence. The District is focused on eliminating combined system overflows and reducing overall volume to the regional system.

Spirit Rock Climbing Gym

Kimberly, BC – The Spirit Rock Climbing Gym is located in Kimberly, BC. It features 6000 square feet of indoor and outdoor roped climbing, reaching heights of 50 feet and includes a 16 foot high top out bouldering area. In 2013, McElhanney provided geotechnical engineering and site reviews for the building foundation as well as structural engineering and inspection services for the climbing surfaces.

Southwest Calgary Ring Road

Calgary, AB – The Government of Alberta and the City of Calgary began planning for the Calgary Ring Road in the 1970s. Throughout the 1980s and 1990s, the province purchased most of the land needed for the transportation utility corridor around Calgary where the ring road would be built. The northwest, northeast, and southeast sections are now in operation – known collectively as Stoney Trail – and motorists now have 70km of free-flow travel.

Simon Fraser University Scan to BIM

Burnaby, BC – McElhanney conducted several laser scan surveys at SFU to assist with a variety of renovation and upgrade projects. Our team of modelling technicians converted the resulting point cloud exports into 3D Building Information Models (BIM) which are used directly by the architectural project team.

Sea to Sky Highway Improvements

Whistler to Vancouver, BC – The Sea to Sky Highway links communities from Whistler to Vancouver. The highway was first paved in 1966 and for many years had only a single lane of traffic in each direction. As populations grew and the economy developed, collisions and accidents increased along the corridor.
