The budget-friendly re-design included a much-needed new bypass around the lift station for emergency or other temporary use. Through intricate design, the team managed to tie it in with existing, unused infrastructure to save the Town added expense.
The survey work for the intake tower included GPS, 3D laser scanning, UAV, and multi-beam bathymetry. The team used GPS to establish primary control from which to base the survey, and then extended that control network around the site with a conventional total station.
The Town of High River, Alberta has won two awards for its innovative new Land Use Bylaw (LUB). McElhanney worked with the Town to re-write the LUB based entirely on walkability; the first of its kind in Alberta. It won a provincial Award of Merit from the Alberta Professional Planners Institute (APPI) on October 2, 2018.…
Ross Road is located between Mountain Highway and Allan Road in North Vancouver. McElhanney is designing replacement bridges for the aging Coleman Creek and Hastings Creek Bridges. This involves raising both the roadway approaches and bridges to achieve the maximum freeboard possible.
3D Photorealistic renders were required to showcase the design of this roundabout. CAD files were provided to model the roundabout as well as the terrain. After adding textures, lights and 3D models the renders were retouched to produce the final 3D imagery. The Contractor used these renderings to communicate the project to residents and stakeholders.
This Virtual Reality experience shows the potential of this technology and its benefits for project proposals, public forums, marketing, stakeholder engagement, and more. Laser scanned data, CAD models, and 3D models were used along with programming to create this fully immersive experience.
