Port Mann Bridge Aerial

Port Mann Highway 1 Roadworks and Detour Designs

During construction, more than 120,000 vehicles drove over the Port Mann Bridge every day, ranging from commuters (travelling 80km/h) to slow-moving construction machinery. The detour designs needed to incorporate HOV lanes, cycling lanes, and dedicated bus and truck ramps, and ensure high-speed and low-speed traffic did not mix.

Read more
Atal Setu

Veer Kunwar Singh Setu

The Veer Kunwar Singh Setu is a four lane highway bridge over the Ganga (Ganges) River near Patna in Bihar, India. It was procured through a Design-Build contract. McElhanney successfully value engineered an extradosed segmental bridge concept with 16 back-to-back 120m-long spans that reduced construction duration and material consumption for the 1,920m navigation spans portion of the 4km bridge. Approach spans outside the navigation spans utilizes precast segmental erected in span-by-span. The bridge opened in June 2017.

Read more
Uplands Combined Sewer Separation

Uplands Combined Sewer Separation

McElhanney developed six options for Upland’s separate sewer and stormwater systems with service to each residence. The District is focused on eliminating combined system overflows and reducing overall volume to the regional system.

Read more
Spirit Rock Climbing Gym

Spirit Rock Climbing Gym

Kimberly, BC – The Spirit Rock Climbing Gym is located in Kimberly, BC. It features 6000 square feet of indoor and outdoor roped climbing, reaching heights of 50 feet and includes a 16 foot high top out bouldering area. In 2013, McElhanney provided geotechnical engineering and site reviews for the building foundation as well as structural engineering and inspection services for the climbing surfaces.

Read more
Southwest Calgary Ring Road

Southwest Calgary Ring Road

Calgary, AB – The Government of Alberta and the City of Calgary began planning for the Calgary Ring Road in the 1970s. Throughout the 1980s and 1990s, the province purchased most of the land needed for the transportation utility corridor around Calgary where the ring road would be built. The northwest, northeast, and southeast sections are now in operation – known collectively as Stoney Trail – and motorists now have 70km of free-flow travel.

Read more
Simon Fraser University Scan to BIM

Simon Fraser University Scan to BIM

Burnaby, BC – McElhanney conducted several laser scan surveys at SFU to assist with a variety of renovation and upgrade projects. Our team of modelling technicians converted the resulting point cloud exports into 3D Building Information Models (BIM) which are used directly by the architectural project team.

Read more
Sea to Sky Highway Improvements

Sea to Sky Highway Improvements

Whistler to Vancouver, BC – The Sea to Sky Highway links communities from Whistler to Vancouver. The highway was first paved in 1966 and for many years had only a single lane of traffic in each direction. As populations grew and the economy developed, collisions and accidents increased along the corridor.

Read more
Sapperton Transportation Plan

Sapperton Transportation Plan

New Westminster, BC – The Sapperton neighbourhood in New Westminster, BC is experiencing significant growth. The Royal Columbian Hospital is undergoing a major expansion for the next decade. New mixed-use developments such as the Brewery District and Sapperton Green are bringing in employment opportunities and hundreds of new residents, and new major infrastructure including the Pattullo Bridge replacement and interchange upgrades planned for Brunette Avenue at Highway 1, will significantly impact traffic volumes and goods movement on neighbourhood streets.

Read more
