Ross Road is located between Mountain Highway and Allan Road in North Vancouver. McElhanney is designing replacement bridges for the aging Coleman Creek and Hastings Creek Bridges. This involves raising both the roadway approaches and bridges to achieve the maximum freeboard possible.
McElhanney gathered laser scanned data, converted it into a 3D model, then brought it into Virtual Reality software. This is a relatively simple virtual reality experience where the user can move around the station by walking or teleporting.
The 3D visualization for this project needed to show what No. 2 Road would look like after the widening between Steveston Highway and London Road was finished. Our team took photos from 5 specific locations to so the surroundings in the rendering could be accurate.
3D Photorealistic renders were required to showcase the design of this roundabout. CAD files were provided to model the roundabout as well as the terrain. After adding textures, lights and 3D models the renders were retouched to produce the final 3D imagery. The Contractor used these renderings to communicate the project to residents and stakeholders.
McElhanney provided bridge design and engineering services for the Sultanganj bridge project. Our team created 3D photorealistic renderings to illustrate the article. This rendering included a detailed 3D model with textures, scenery, and vehicle traffic.
McElhanney is providing a wide array of services for this project including structural, civil, and hydrological engineering, environmental, visualization, and arborist services. McElhanney developed the images to help illustrate the project concept.
Since 2008, McElhanney has completed over 300 assignments for Parks Canada. This includes emergency response services for major floods in Banff, Jasper, and Kootenay National Parks in 2012 and 2013, as well as avalanche cleanup in Banff National Park in 2017.
Following severe rain in June 2011, Hwy 97 experienced floods between Pine Pass and 20km south of Chetwynd (a length of 60km), with 73 damaged sites. This flooding resulted in the loss of culverts and bridge end fills, and washouts along various portions of the highway, forcing closure of this vital route.
The Warman & Martensville Interchanges or Overpasses located on Highway 12 at Martensville and Highway 11 at Warman, will improve safety for two of the fastest growing communities in Saskatchewan.
McElhanney was retained by Parks Canada Agency to provide the following services: roadway and surfacing design; geotechnical and materials testing; drainage review and design; utility coordination; integration of bridges, lighting, signing; construction administration; road safety audits and upgrades; and surveying.
